Platform Series-HS-900
TECHNICAL SPECIFICATION
|
|
Handpiece | 2940nm Er:YAG fractional ablative laser |
| Spot size | 10x10mmΦ6mm, Φ9mm, Φ1-3.4mm | |
| Energy | 7x7 pixel: 12-28mJ/MTZ9x9 pixel: 4-20mJ/MTZBeam expander: 500-2000mJZoom lens: 500-2000mJ | |
| Pulse width | 1.5ms, 2ms, 2.5ms | |
 |
Handpiece | 1540nm Er:Glass fractional laser |
| Energy | 10x10 pixel: 30-70mJ/MTZ18x18 pixel: 5-25mJ/MTZ | |
| Pulse width | 10ms, 15ms | |
 |
Handpiece | 1064nm Long Pulse ND:YAG Laser |
| Pulse width | 10-40ms | |
| Repetition rate | 0.5-1Hz | |
| Energy density | Φ9mm: 10-110J/cm2Φ6mm: 60-260J/cm2Φ2.2*5mm: 150-500J/cm2 | |
 |
Handpiece | 1064/532nm Q-switch ND:YAG Laser |
| Spot size | 1-5mm | |
| Pulse width | ＜10ns (single pulse) | |
| Repetition rate | 1-10Hz | |
| Max. Energy | 2400mJ-4700mJ | |
 |
Handpiece | IPL SHR/EPL |
| Spot size | 15*50mm | |
| Wavelength | 420-1200nm | |
| Filter | 420/510/560/610/640-1200nm, SHR filter | |
| Energy | 10-60 level | |
 |
Handpiece | RF Monopolar or RF Bipolar |
| Output power | 200W | |
| RF tip | Φ18mm, Φ28mm, Φ37mm | |
| Operate interface | 8’ true color touch screen | |
| Dimension | 65*48*115cm (L*W*H) | |
| Weight | 72Kgs |
ADVANTAGES
TUV Medical CE approved
Handpieces interchangeable and auto-detected
Numerous aesthetic/medical applications
High output energy for amazing efficacy
Smart software upgradable
High patient and clinical staff satisfaction
|
|
Handpiece | 2940nm Er:YAG fractional ablative laser |
| Spot size | 10x10mmΦ6mm, Φ9mm, Φ1-3.4mm | |
| Energy | 7×7 pixel: 12-28mJ/MTZ9x9 pixel: 4-20mJ/MTZBeam expander: 500-2000mJZoom lens: 500-2000mJ | |
| Pulse width | 1.5ms, 2ms, 2.5ms | |
 |
Handpiece | 1540nm Er:Glass fractional laser |
| Energy | 10×10 pixel: 30-70mJ/MTZ18x18 pixel: 5-25mJ/MTZ | |
| Pulse width | 10ms, 15ms | |
 |
Handpiece | 1064nm Long Pulse ND:YAG Laser |
| Pulse width | 10-40ms | |
| Repetition rate | 0.5-1Hz | |
| Energy density | Φ9mm: 10-110J/cm2Φ6mm: 60-260J/cm2Φ2.2*5mm: 150-500J/cm2 | |
 |
Handpiece | 1064/532nm Q-switch ND:YAG Laser |
| Spot size | 1-5mm | |
| Pulse width | ＜10ns (single pulse) | |
| Repetition rate | 1-10Hz | |
| Max. Energy | 2400mJ-4700mJ | |
 |
Handpiece | IPL SHR/EPL |
| Spot size | 15*50mm | |
| Wavelength | 420-1200nm | |
| Filter | 420/510/560/610/640-1200nm, SHR filter | |
| Energy | 10-60 level | |
 |
Handpiece | RF Monopolar or RF Bipolar |
| Output power | 200W | |
| RF tip | Φ18mm, Φ28mm, Φ37mm | |
| Operate interface | 8’ true color touch screen | |
| Dimension | 65*48*115cm (L*W*H) | |
| Weight | 72Kgs |
TREATMENT APPLICATION
| 2940nm Er:YAG fractional ablative laser | Skin resurfacing, Wrinkle and fine linesPhotodamage, Texture irregularityWart and nevus removal |
| 1540nm Er:Glass fractional laser | Skin resurfacing, Surgical scar, acne scarStretch marks, Melasma, Wrinkle |
| 1064nm Long Pulse ND:YAG Laser | Hair removal for all skin typesLeg veins, Vascular lesionWrinkle removal |
| 1064/532nm Q-switch ND:YAG Laser | Tattoo and tattoo wound removalEyebrow, soak lip line removalEpidermal/dermal lesion pigmentedVascular lesions(telangiectasis)Soft peeling |
| IPL SHR/EPL | Permanent hair removal, Acne removalSkin toning, Skin rejuvenationEpidermal pigment removalSpots and freckle removalSkin firming and tighteningVascular treatment |
| RF Monopolar or RF Bipolar | Sculpture, Cellulite treatmentSkin tightening, Deep wrinkle removalMake pore contractedImprove skin-metabolismAlleviate oily acne, eye pouch |
