Diode Laser HS-811

Short Description:

EUROPEAN 93/42/EEC MEDICAL STANDARD DIODE LASER, TUV Medical CE approved system. It combines three different wavelengths in same unit that all kinds of patients can be treated without limitation of phototype, hair type or time of year with the maximum effectiveness and security.


Product Detail

Specification

Application

Before & After

Video

Diode Laser HS-810 811 new version

EUROPEAN 93/42/EEC MEDICAL STANDARD DIODE LASER, TUV Medical CE approved system. It combines three different wavelengths in same unit that all kinds of patients can be treated without limitation of phototype, hair type or time of year with the maximum effectiveness and security.

CONTACT COOLING SAPPHIRE TIP

The laser handpiece head is fitted with sapphire tip that increase safety of the patients and minimises pain during treatment. Ensuring a constant temperature of -4℃ to 4℃ at the tip of handpiece, allowing it to work with high power and big spot size guaranteeing the safety of treatment.

DIFFERENT SPOT SIZE & POWER

Various spot size available to meet different demand of customers for depilation.

810nm Triplewave

00001

600W
12x16mm

810nm Triplewave

00003

800W
12x20mm

810nm Triplewave

00003

600W
12x20mm

SMART PRE-SET TREATMENT PROTOCOLS

You can adjust the settings precisely in PROFESSIONAL MODE for the skin, colour and hair type and the hair thickness, thereby offering clients maximum safety and effectiveness in their personalised treatment.

Using the intuitive touch screen, you can select the required mode and programmes. The device recognises different handpiece types used and automatically adapts the configuration circle to it, giving pre-set recommended treatment protocols.

1-1
4-专业治疗界面

  • Previous:
  • Next:

  • Laser output

    600W

    Spot size

    12*16mm

    Wavelength

    810nm

    Triplewave

    Energy density

    1-90J/cm2

    1-90J/cm2

    Laser output

    800W

    Spot size

    12*20mm

    Wavelength

    810nm

    Triplewave

    Energy density Max.

    1-125J/cm2

    1-98J/cm2

    Laser output

    800W

    Spot size

    12*16mm

    Wavelength

    810nm

    Triplewave

    Energy density Max.

    1-120J/cm2

    1-90J/cm2

    Repetition rate

    1-10HZ

    Pulse width

    10-400ms

    Sapphire contact cooling

    -4~4℃

    Operate interface

    8’’ True color touch screen

    Dimension

    56*38*110cm (L*W*H)

    Weight

    55Kgs

    Treatment Application

    z 755nm: recommended for white skin (phototypes I-III) with fine/blond hair.
    z 810nm: Golden standard for depilation, recommended for treating all skin phototypes, particularly patients with a great density of hair.
    z 1064nm: indicated for dark phototypes(III-IV tanned, V and VI).
